Toyota RAV4 Key Fob Programming
Updated 2026 1996–2016 21 model years
Programming steps, the battery it takes, and the exact replacement fob for every Toyota RAV4 model year we cover (1996–2016). Find your year in the table, then jump to the details for that generation.
Every Toyota RAV4 model year
| Year | Programming | Key fob | Battery |
|---|---|---|---|
| 2016 |
| Proximity Key, Remote Head Key · 3/4-button | CR2032 battery on Amazon |
| 2015 |
| Proximity Key, Remote Head Key · 3/4-button | CR2032 battery on Amazon |
| 2014 |
| Proximity Key, Remote Head Key · 3/4-button | CR2032 battery on Amazon |
| 2013 |
| Proximity Key, Remote Head Key, Transponder Key · 3/4-button | CR2032 battery on Amazon |
| 2012 |
| Proximity Key, Remote Head Key, Transponder Key · 3-button | CR1632 battery on Amazon |
| 2011 |
| Proximity Key, Remote Head Key, Remote, Transponder Key · 2/3-button | CR1632 battery on Amazon |
| 2010 |
| Proximity Key, Remote Head Key, Remote, Transponder Key · 2/3-button | CR1632 battery on Amazon |
| 2009 |
| Proximity Key, Remote Head Key, Remote, Transponder Key · 2/3-button | CR1632 battery on Amazon |
| 2008 |
| Proximity Key, Remote Head Key, Remote, Transponder Key · 2/3-button | CR1632 battery on Amazon |
| 2007 |
| Remote Head Key, Remote, Transponder Key · 2/3-button | CR2025 battery on Amazon |
| 2006 |
| Remote Head Key, Remote, Transponder Key · 2/3-button | CR2025 battery on Amazon |
| 2005 |
| Remote, Transponder Key · 2/3-button | CR2016 battery on Amazon |
| 2004 |
| Remote, Transponder Key · 2/3-button | CR2016 battery on Amazon |
| 2003 |
| Remote, Transponder Key · 2/3-button | CR2016 battery on Amazon |
| 2002 |
| Remote, Transponder Key · 2/3-button | CR2016 battery on Amazon |
| 2001 |
| Remote, Transponder Key · 2/3-button | CR2016 battery on Amazon |
| 2000 |
| Transponder Key, Remote · 2-button | CR2025 battery on Amazon |
| 1999 |
| Transponder Key, Remote · 2-button | CR2025 battery on Amazon |
| 1998 |
| Transponder Key, Remote · 2-button | CR2025 battery on Amazon |
| 1997 |
| Transponder Key | None (chip key) |
| 1996 |
| Transponder Key | None (chip key) |
2016 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3/4-button Proximity Key
Find on Amazon- FCC ID
- HYQ14FBA
- OE part #
- 89904-0R080, 89904-42070, 89904-52290
- Frequency
- 315 MHz
- Chip
- TEX INST 4D74 128-BIT
Remote Head Key
3 versionsOne piece: a cut metal blade with the lock/unlock buttons built into the head.
3/4-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDM
- OE part #
- 89070-42820, 89070-42830, 89070-42D30, 89070-42D40, 89070-52F50
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3/4-button Remote Head Key
Find on Amazon- FCC ID
- GQ4-52T
- OE part #
- 89070-0C050, 89070-0C060, 89070-0R100, 89070-0R101, 89070-0R120, 89070-0R121 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
4-button Remote Head Key
Find on Amazon- FCC ID
- CANADIANONLY, HYQ12BDP
- OE part #
- 89070-0R221, 890700R221
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 74 128 BIT H
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2015 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3/4-button Proximity Key
Find on Amazon- FCC ID
- HYQ14FBA
- OE part #
- 89904-0R080, 89904-42070, 89904-52290
- Frequency
- 315 MHz
- Chip
- TEX INST 4D74 128-BIT
Remote Head Key
3 versionsOne piece: a cut metal blade with the lock/unlock buttons built into the head.
3/4-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDM
- OE part #
- 89070-42820, 89070-42830, 89070-42D30, 89070-42D40, 89070-52F50
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3/4-button Remote Head Key
Find on Amazon- FCC ID
- GQ4-52T
- OE part #
- 89070-0C050, 89070-0C060, 89070-0R100, 89070-0R101, 89070-0R120, 89070-0R121 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3/4-button Remote Head Key
Find on Amazon- FCC ID
- CANADIANONLY, HYQ12BDP
- OE part #
- 89070-04020, 89070-0A150, 89070-0E130, 89070-0R130, 89070-0R221, 89070-12590 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 74 128 BIT H
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2014 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3/4-button Proximity Key
Find on Amazon- FCC ID
- HYQ14FBA
- OE part #
- 89904-0R080, 89904-42070, 89904-52290
- Frequency
- 315 MHz
- Chip
- TEX INST 4D74 128-BIT
Remote Head Key
3 versionsOne piece: a cut metal blade with the lock/unlock buttons built into the head.
3/4-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDM
- OE part #
- 89070-42820, 89070-42830, 89070-42D30, 89070-42D40, 89070-52F50
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3/4-button Remote Head Key
Find on Amazon- FCC ID
- GQ4-52T
- OE part #
- 89070-0C050, 89070-0C060, 89070-0R100, 89070-0R101, 89070-0R120, 89070-0R121 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDP
- OE part #
- 89070-04020, 89070-0A150, 89070-0E130, 89070-0R130, 89070-12590
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 74 - 128 BIT H CHIP
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2013 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3/4-button Proximity Key
Find on Amazon- FCC ID
- HYQ14FBA
- OE part #
- 89904-0R080, 89904-42070, 89904-52290
- Frequency
- 315 MHz
- Chip
- TEX INST 4D74 128-BIT
Remote Head Key
3 versionsOne piece: a cut metal blade with the lock/unlock buttons built into the head.
3/4-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDM
- OE part #
- 89070-42820, 89070-42830, 89070-42D30, 89070-42D40, 89070-52F50
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3/4-button Remote Head Key
Find on Amazon- FCC ID
- GQ4-52T
- OE part #
- 89070-0C050, 89070-0C060, 89070-0R100, 89070-0R101, 89070-0R120, 89070-0R121 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D H
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BDP
- OE part #
- 89070-04020, 89070-0A150, 89070-0E130, 89070-0R130, 89070-12590
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 74 - 128 BIT H CHIP
Transponder Key
A cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2012 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3-button Proximity Key
Find on Amazon- FCC ID
- HYQ14AAB, HYQ14AEM
- OE part #
- 89904-06041, 89904-07030, 89904-0R060, 89904-0R090, 89904-35030, 89904-42140 +5 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 60 80-BIT
Remote Head Key
One piece: a cut metal blade with the lock/unlock buttons built into the head.
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BBY, HYQ12BDC
- OE part #
- 89070-0R050, 89070-35170, 89070-42540, 89070-42660, 89070-42670, 89070-42750 +1 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 72 G CHIP
Transponder Key
2 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Transponder Key
Find on Amazon- Key blank
- 89785-08040, TOY44GPT
- OE part #
- 89785-08040, TOY44G, TOY44G-PT, TOY44GPT, TR52G-PHT
- Chip
- 4D-72 G 80-BIT
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2011 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3-button Proximity Key
Find on Amazon- FCC ID
- HYQ14AAB, HYQ14AEM
- OE part #
- 89904-06041, 89904-07030, 89904-0R060, 89904-0R090, 89904-35030, 89904-42140 +5 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 60 80-BIT
Remote Head Key
One piece: a cut metal blade with the lock/unlock buttons built into the head.
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BBY, HYQ12BDC
- OE part #
- 89070-0R030, 89070-0R050, 89070-12380, 89070-35170, 89070-42540, 89070-42660 +3 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 67 DOT CHIP
Remote
2 versionsA separate key fob that only handles locking and unlocking.
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
2 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Transponder Key
Find on Amazon- Key blank
- 89785-08040, TOY44GPT
- OE part #
- 89785-08040, TOY44G, TOY44G-PT, TOY44GPT, TR52G-PHT
- Chip
- 4D-72 G 80-BIT
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2010 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3-button Proximity Key
Find on Amazon- FCC ID
- HYQ14AAB, HYQ14AEM
- OE part #
- 89904-06041, 89904-07030, 89904-0R060, 89904-0R090, 89904-35030, 89904-42140 +5 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 60 80-BIT
Remote Head Key
One piece: a cut metal blade with the lock/unlock buttons built into the head.
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BBY, HYQ12BDC
- OE part #
- 89070-0R030, 89070-0R050, 89070-12380, 89070-35170, 89070-42540, 89070-42660 +3 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 67 DOT CHIP
Remote
2 versionsA separate key fob that only handles locking and unlocking.
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
3 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Transponder Key
Find on Amazon- Key blank
- 89785-08040, TOY44GPT
- OE part #
- 89785-08040, TOY44G, TOY44G-PT, TOY44GPT, TR52G-PHT
- Chip
- 4D-72 G 80-BIT
Transponder Key
Find on Amazon- Key blank
- TOY44DPT
- OE part #
- 5910834, 89785-08020
- Chip
- 4D-67 DOT
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2008–2009 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Proximity Key
Stays in your pocket — the car unlocks and starts without inserting a key.
3-button Proximity Key
Find on Amazon- FCC ID
- HYQ14AAB, HYQ14AEM
- OE part #
- 89904-06041, 89904-07030, 89904-0R060, 89904-0R090, 89904-35030, 89904-42140 +2 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 60 80-BIT
Remote Head Key
One piece: a cut metal blade with the lock/unlock buttons built into the head.
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BBY, HYQ12BDC
- OE part #
- 89070-0R030, 89070-0R050, 89070-12380, 89070-35170, 89070-42540, 89070-42660 +3 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 67 DOT CHIP
Remote
2 versionsA separate key fob that only handles locking and unlocking.
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
2 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Transponder Key
Find on Amazon- Key blank
- TOY44DPT
- OE part #
- 5910834, 89785-08020
- Chip
- 4D-67 DOT
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2006–2007 Toyota RAV4
Remote / key fob programming
This remote can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new remote, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement remote below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Remote Head Key
One piece: a cut metal blade with the lock/unlock buttons built into the head.
3-button Remote Head Key
Find on Amazon- FCC ID
- HYQ12BBY, HYQ12BDC
- OE part #
- 89070-0R030, 89070-0R050, 89070-12380, 89070-35170, 89070-42540, 89070-42660 +3 more
- Frequency
- 315 MHz
- Chip
- TEXAS ID 4D 67 DOT CHIP
Remote
2 versionsA separate key fob that only handles locking and unlocking.
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
2 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Transponder Key
Find on Amazon- Key blank
- TOY44DPT
- OE part #
- 5910834, 89785-08020
- Chip
- 4D-67 DOT
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
2001–2005 Toyota RAV4
Remote / key fob programming
You can program Toyota remotes yourself with a sequence of door and ignition movements. Have every remote with you. Try the main procedure first; if the locks don't cycle, use the alternate.
Full steps: Toyota Remote Programming With a Door and Ignition Sequence
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Remote
3 versionsA separate key fob that only handles locking and unlocking.
3-button Remote
Find on Amazon- FCC ID
- HYQ12BAN, HYQ12BBX
- OE part #
- 5931638, 89742-0C020, 89742-20200, 89742-42120, 89742-52010
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
5 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- AF01435113
- OE part #
- X217
Transponder Key
Find on Amazon- Key blank
- AF01503012
- OE part #
- X225
Transponder Key
Find on Amazon- Key blank
- GMB80
- OE part #
- GM-24
Transponder Key
Find on Amazon- Key blank
- TOYO-15E
- OE part #
- TOYO-15, TR47, X217
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
1998–2000 Toyota RAV4
Remote / key fob programming
You can program Toyota remotes yourself with a sequence of door and ignition movements. Have every remote with you. Try the main procedure first; if the locks don't cycle, use the alternate.
Full steps: Toyota Remote Programming With a Door and Ignition Sequence
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Remote
2 versionsA separate key fob that only handles locking and unlocking.
2-button Remote
Find on Amazon- FCC ID
- BAB237131-022
- OE part #
- 08191-00870, PT398-07100
- Frequency
- 315 MHz
2-button Remote
Find on Amazon- FCC ID
- BAB237131-013
- OE part #
- 00398-00913, 00398-00923, 08191-00840, 08191-00841, 08191-00850, 08191-00860 +1 more
- Frequency
- 315 MHz
Transponder Key
5 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- AF01435113
- OE part #
- X217
Transponder Key
Find on Amazon- Key blank
- AF01503012
- OE part #
- X225
Transponder Key
Find on Amazon- Key blank
- GMB80
- OE part #
- GM-24
Transponder Key
Find on Amazon- Key blank
- TOYO-15E
- OE part #
- TOYO-15, TR47, X217
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
1996–1997 Toyota RAV4
Remote / key fob programming
You can program Toyota remotes yourself with a sequence of door and ignition movements. Have every remote with you. Try the main procedure first; if the locks don't cycle, use the alternate.
Full steps: Toyota Remote Programming With a Door and Ignition Sequence
Key programming
This key fob can't be programmed with a do-it-yourself procedure. The vehicle needs a diagnostic tool connected to its OBD port to pair a new fob, so a replacement has to be set up by an automotive locksmith or a dealer.
Order the correct replacement fob below — match the FCC ID on your current fob first — then have a local automotive locksmith or the dealer program it to your vehicle.
Replacement key fobs
Find your key type below, then match the FCC ID printed on the back of your existing fob — or, for a plain transponder key, the blank code — to be sure of the right part.
Transponder Key
5 versionsA cut metal key with a chip in the head. No buttons.
Transponder Key
Find on Amazon- Key blank
- AF01435113
- OE part #
- X217
Transponder Key
Find on Amazon- Key blank
- AF01503012
- OE part #
- X225
Transponder Key
Find on Amazon- Key blank
- GMB80
- OE part #
- GM-24
Transponder Key
Find on Amazon- Key blank
- TOYO-15E
- OE part #
- TOYO-15, TR47, X217
Transponder Key
Find on Amazon- Key blank
- TR47-P
- OE part #
- TR47-P
Photos show the OEM part for each number listed. Aftermarket replacements sold online are often slightly different in appearance — the FCC ID, not the shape, is what determines whether a fob will work with your car.
- 1996–1997
- No battery
- 1998–2000, 2006–2007
- CR2025 battery on Amazon
- 2001–2005
- CR2016 battery on Amazon
- 2008–2009, 2010, 2011, 2012
- CR1632 battery on Amazon
- 2013, 2014, 2015, 2016
- CR2032 battery on Amazon
1996–1997 Toyota RAV4 key fob battery
A plain transponder (chip) key has no battery. The immobilizer chip inside is powered by the car's ignition ring whenever you turn the key, so there's nothing to replace. If your key also has lock/unlock buttons, that remote portion uses a 3V coin cell — see the remote battery steps for that.
Battery tips
- If your engine won't start but the key turns, the issue is usually a worn key or the immobilizer reading the chip — not a battery.
- A spare chip key must be cut and programmed to your car before it will start the engine.
1998–2000, 2006–2007 Toyota RAV4 key fob battery
Your 1998–2000, 2006–2007 Toyota RAV4 key fob uses a CR2025 3V lithium coin cell. A fresh one typically lasts 3–5 years.
Buy Energizer CR2025 Lithium Coin Batteries (4-pack) on AmazonHow to replace the battery
- 1 Find the seam or small slot on the edge of the remote.
- 2 Twist a coin or small flathead in the slot to split the case open.
- 3 Remove the old coin cell and note the + side.
- 4 Fit the new battery with the + side matching, then close the case.
- 5 Press a button to confirm the LED lights, then test at the car.
Battery tips
- Use a fresh, name-brand 3V lithium cell — bargain cells drain quickly.
- Try not to touch both faces of the new battery; skin oils shorten its life.
- If the remote still doesn't work after a new battery, it may need re-syncing or programming.
2001–2005 Toyota RAV4 key fob battery
Your 2001–2005 Toyota RAV4 key fob uses a CR2016 3V lithium coin cell. A fresh one typically lasts 3–5 years.
Buy Energizer CR2016 Lithium Coin Batteries (2-pack) on AmazonHow to replace the battery
- 1 Find the seam or small slot on the edge of the remote.
- 2 Twist a coin or small flathead in the slot to split the case open.
- 3 Remove the old coin cell and note the + side.
- 4 Fit the new battery with the + side matching, then close the case.
- 5 Press a button to confirm the LED lights, then test at the car.
Battery tips
- Use a fresh, name-brand 3V lithium cell — bargain cells drain quickly.
- Try not to touch both faces of the new battery; skin oils shorten its life.
- If the remote still doesn't work after a new battery, it may need re-syncing or programming.
2008–2009, 2010, 2011, 2012 Toyota RAV4 key fob battery
Your 2008–2009, 2010, 2011, 2012 Toyota RAV4 key fob uses a CR1632 3V lithium coin cell. A fresh one typically lasts 3–5 years.
Buy Energizer CR1632 Lithium Coin Batteries (2-pack) on AmazonHow to replace the battery
- 1 Slide the release latch and pull the metal emergency key out of the fob.
- 2 Use that key (or a coin) to pry the two halves apart at the seam.
- 3 Lift out the old coin cell — note which side faces up.
- 4 Drop in the new battery the same way (printed + side usually faces the back cover).
- 5 Press the case back together until it clicks, then test lock/unlock and push-to-start.
Battery tips
- Use a fresh, name-brand 3V lithium cell — bargain cells drain quickly.
- Even with a dead fob battery you can usually still start the car by holding the fob against the start button — check your owner's manual.
- If the fob still won't work after a new battery, it may need re-syncing or programming.
2013, 2014, 2015, 2016 Toyota RAV4 key fob battery
Your 2013, 2014, 2015, 2016 Toyota RAV4 key fob uses a CR2032 3V lithium coin cell. A fresh one typically lasts 3–5 years.
Buy Energizer CR2032 Lithium Coin Batteries (4-pack) on AmazonHow to replace the battery
- 1 Slide the release latch and pull the metal emergency key out of the fob.
- 2 Use that key (or a coin) to pry the two halves apart at the seam.
- 3 Lift out the old coin cell — note which side faces up.
- 4 Drop in the new battery the same way (printed + side usually faces the back cover).
- 5 Press the case back together until it clicks, then test lock/unlock and push-to-start.
Battery tips
- Use a fresh, name-brand 3V lithium cell — bargain cells drain quickly.
- Even with a dead fob battery you can usually still start the car by holding the fob against the start button — check your owner's manual.
- If the fob still won't work after a new battery, it may need re-syncing or programming.
We may earn a commission on qualifying purchases made through links on this page, at no extra cost to you. It never affects which product we recommend. Learn more.
Rather hire a pro?
See what it actually costs, broken out by dealer, locksmith, and DIY:
